Description
The HP15X2 is a range of professional two-channel stereo power amplifiers that offer a high-power output and individual volume control for each channel. With flexible input options, LED working status indication and various protection features, this series is great for large events and sound reinforcement in different occasions.
Specifications
Model
HP15X2
Rated Output / Per Channel, 8Ω
150W
Rated Output / Per Channel, 4Ω
250W
Rated Output / Bridge, 8Ω
500W
Input Sensitivity
600mV
SNR
≥100dB
Damping Coefficient/8Ω,1kHz
200:1
Input Common-Mode Rejection
> 90dB
Frequency Response
20Hz-20kHz(±3dB)
Harmonic Distortion Factor4Ω/1kHz
< 0.1%
Channel Impedance
4-16Ω
Channel Crosstalk
<-70dB Voltage Gain > 38dB
Display
“POWER”, “CLIP”, “SIGNAL”,
“DC”, “TEMP” and other LED indicators
Power Supply
AC220V/50Hz
Protection
Power Off, DC Output, Load Short Circuit
Product Size (mm)
(L×W×H)484×446×88 (2U)
Package Size (mm)
(L×W×H)535×530×195
G/W
17.2 kg
N/W
15.2kg
